Part
Number |
Number
of turns
per
Winding |
Operating
Frequency
Range |
Insertion
Loss |
Fig. |
Double Balanced
Mixer
456DB-1013 |
1 |
50MHz~400MHz |
10dB max. |
1 |
| 456DB-1014 |
2 |
10MHz~1.0GHz |
6dB max. |
1 |
| 456DB-1005 |
3 |
8MHz~800MHz |
3.5dB max. |
1 |
| 456DB-1006 |
4 |
6MHz~600MHz |
2.5dB max. |
1 |
| 456DB-1007 |
5 |
5MHz~500MHz |
2dB max. |
1 |
| 456DB-1009 |
2 |
400MHz~1.3GHz |
4dB max. |
1 |
Distributor
456DS-1012 |
|
20MHz~600MHz |
IN to OUT-1, 2
4.5db
max
OUT-1 to OUT-2
(ISOLATION)
10dB
min. |
2 |
Directional
Coupler
456PS-1015 |
4 |
6MHz~600MHz |
IN to OUT-1 1.3dB max.
IN to
OUT-2 11dB ~ 14dB |
3 |
| 456PS-1016 |
5 |
6MHz~600MHz |
IN to OUT-1 0.9dB max.
IN to
OUT-2 13dB ~16dB |
3 |
| 456PS-1011 |
6 |
6MHz~600MHz |
IN to OUT-1 0.8dB max.
IN to
OUT-2 15dB ~ 17dB |
3
|
